NV Green and Ampt Upload

Select a Subbasin .zip file:

A zipped polygon shapefile that contains a field (text or number) that represents a unique indentifier for each subbasin.

Select a Landuse .zip file:

A zipped polygon shapefile that includes information for interpreting % impervious (directly connect to outlet), initial moisture condition (component of DTHETA parameter), and surface storage (used in HEC-HMS).

Enter the subbasin name field:

The name of the field in the subbasins shapefile that contains unique identifiers for each subbasin.

Enter the land-use moisture field name:

A text field in the land-use shapefile that contains the assumed moisture condition for each land-use. Valid values areDry:"d", "dry", "D", "DRY"Field Capacity ("normal" moisture condition, moist):"m", "moist", "M", "MOIST"Saturated:"s", "sat", "S", "SAT"

Enter the land-use storage field name:

The depth of surface storage, in inches, for each land-use area. Please refere to NDOT reference material for selection of appropriate values. In general, values should not exceed 0.35 inches except for agricultural areas which may reach 0.5 inches.

Enter the land-use directly-connected impervious area field name:

The percent, expressed as a decimal from 0 to 100, of impervious area for each land-use area which is directly connected to a basin outlet.

Enter the land-use vegetative cover field name:

Percent (0-100) of vegetative cover per land-use polygon. Not to be used in 2D models for FCDMC and not to be used for NDOT without prior authorization.
